Hardware Installation - 10 -
1-2 Product Specications
CPU
w
Support for an Intel
®
Core
™
i7 series processor/Intel
®
Core
™
i5 series processor/
Intel
®
Core
™
i3 series processor in the LGA1156 package
(Go to GIGABYTE's website for the latest CPU support list.)
w
L3 cache varies with CPU
Chipset
w
Intel
®
H55 Express Chipset
Memory
w
4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
(Note 1)
w
Dual channel memory architecture
w
Support for DDR3 1666(O.C.)/1333/1066/800 MHz memory modules
w
Support for non-ECC memory modules
w
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Onboard Graphics
w
Integrated in the Chipset:
(Note 2)
- 1 x D-Sub port
- 1 x DVI-D port
(Note 3) (Note 4)
- 1 x HDMI port
(Note 4)
- 1 x DisplayPort
(Note 4)
Audio
w
Realtek ALC889 codec
w
High Denition Audio
w
2/4/5.1/7.1-channel
w
Support for Dolby
®
Home Theater
w
Support for S/PDIF In/Out
w
Support for CD In
LAN
w
1 x Realtek RTL8111E chip (10/100/1000 Mbit)
Expansion Slots
w
1 x PCI Express x16 slot, running at x16
(The PCIEX16 slot conforms to PCI Express 2.0 standard.)
w
3 x PCI Express x1 slots
w
3 x PCI slots
Storage Interface
w
Chipset:
- 5 x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3,
SATA2_4) supporting up to 5 SATA 3Gb/s devices
- 1 x eSATA 3Gb/s connector on the back panel supporting up to 1 SATA 3Gb/s
device
w
GIGABYTE SATA2 chip:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 2 x SATA 3Gb/s connectors (GSATA2_5, GSATA2_6) supporting up to
2 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, and JBOD
w
iTE IT8720 chip:
- 1 x oppy disk drive connector supporting up to 1 oppy disk drive
