Gigabyte GA-H55-USB3 (REV. 2.0) [7/112] Ga h55 usb3 motherboard layout

- 7 -

GA-H55-USB3 Motherboard Layout

KB_USB

VGA_DVI

CPU_FAN

SYS_FAN2

PHASE LED

LGA1156

ATX

GA-H55-USB3

F_AUDIO

AUDIO

M_BIOS

B_BIOS

PCIEX16

IDE

SPDIF_O

DDR3_2

DDR3_1

DDR3_4

DDR3_3

BAT

T.I.

TSB43AB23

ATX_12V_2X4

Intel

H55

GIGABYTE

SATA2

PCIEX1_3

DP_HDMI_SPDIF

USB30_LAN

ESATA_1394_USB

CODEC

SYS_FAN1F_USB1F_USB2COMA

CD_IN

SPDIF_I

F_1394

PWR_FAN

F_PANEL

PCI1

PCI2

Realtek

RTL8111E

SATA2_0

SATA2_1

SATA2_3

GSATA2_6

SATA2_2

SATA2_4

GSATA2_5

NEC

D720200F1

PCIEX1_2

PCIEX1_1

PCI2

PCI3

F_USB3

FDD

CLR_CMOS

iTE

IT8720

F_USB4
