- 43 - BIOS Setup
tRTP
Options are: Auto (default), 1~15.
tFAW
Options are: Auto (default), 1~63.
Command Rate(CMD)
Options are: Auto (default), 1~3.
>>>>> Channel A/B Misc Timing Control
Static tRD
Options are: Auto (default), 1~31.
Advanced Voltage Settings
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Advanced Voltage Settings
******
Mother Board Voltage Control
******
Voltage Types Normal Current
-----------------------------------------------------------------------------
>>> CPU
Load-Line Calibration [Auto]
CPU Vcore 1.17500V [Auto]
Dynamic Vcore(DVID) +0.00000V Auto
QPI/Vtt Voltage 1.100V [Auto]
Graphics Core 1.000V [Auto]
>>> MCH/ICH
PCH Core 1.050V [Auto]
CPU PLL 1.800V [Auto]
>>> DRAM
DRAM Voltage 1.500V [Auto]
DRAM Termination 0.750V [Auto]
Ch-A Data VRef. 0.750V [Auto]
Ch-B Data VRef. 0.750V [Auto]
Ch-A Address VRef. 0.750V [Auto]
Ch-B Address VRef. 0.750V [Auto]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
>>> CPU
Load-Line Calibration
Enables or disables Load-Line Calibration. Enabling this feature adjusts Vdroop, keeping the CPU
voltage more constant under light and heavy CPU load. Disabled sets the CPU voltage following Intel
specications. Auto lets the BIOS automatically congure this setting. (Default: Auto)
Note: Enabling Load-Line Calibration may result in damage to your CPU or reduce the useful life of the
CPU.
CPU Vcore
The default is Auto.
Dynamic Vcore(DVID)
This option is congurable only when CPU Vcore is set to Normal. The default is Auto.
QPI/Vtt Voltage
The default is Auto.
Graphics Core
The default is Auto.
