Hardware Installation - 12 -
(Note 1) Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is
installed, the actual memory size displayed will be less than 4 GB.
(Note 2) To use the onboard DisplayPort, HDMI, DVI-D, and D-Sub ports, you must install an Intel CPU with
integrated graphics.
(Note 3) The DVI-D port does not support D-Sub connection by adapter.
(Note 4) You can use only one of the onboard digital graphics ports (DisplayPort, HDMI, and DVI-D) for out-
put when in the BIOS Setup program or when during the POST screens.
(Note 5) Whether the CPU/system fan speed control function is supported will depend on the CPU/system
cooler you install.
(Note 6) Available functions in EasyTune may differ by motherboard model.
Hardware Monitor
w
System voltage detection
w
CPU/System temperature detection
w
CPU/System/Power fan speed detection
w
CPU overheating warning
w
CPU/System/Power fan fail warning
w
CPU/System fan speed control
(Note 5)
BIOS
w
2 x 64 Mbit ash
w
Use of licensed AWARD BIOS
w
Support for DualBIOS
™
w
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
w
Support for @BIOS
w
Support for Q-Flash
w
Support for Xpress BIOS Rescue
w
Support for Download Center
w
Support for Xpress Install
w
Support for Xpress Recovery2
w
Support for EasyTune
(Note 6)
w
Support for Dynamic Energy Saver
™
2
w
Support for Smart 6
™
w
Support for Auto Green
w
Support for ON/OFF Charge
w
Support for Q-Share
Bundled Software
w
Norton Internet Security (OEM version)
Operating System
w
Support for Microsoft
®
Windows
®
7/Vista/XP
Form Factor
w
ATX Form Factor; 30.5cm x 24.4cm
