Develop ineo 4000P [181/217] Unexpected page breaks occur

Develop ineo 4700P [181/217] Unexpected page breaks occur

User's Guide

- 181 -

Unexpected page breaks occur

Action

Yes

Step 1

Adjust the print timeout settings.

1. From the printer control panel, navigate to:

Settings >General Settings >Timeouts >Print Timeout

2. Select a higher setting and then, depending on your printer model,

select

or Submit.

3. Resend the print job.

Did the file print correctly?

The problem is

solved.

Go to step 2.

Step 2

1. Check the original file for manual page breaks.

2. Resend the print job.

Did the file print correctly?

The problem is

solved.

Contact technical

support.
