Toner fog or background shading appears on prints

Action

Yes

Step 1

Reinstall the imaging unit.

1. Remove, and then install the imaging unit.

2. Resend the print job.

Does fog or shading appear on prints?

Go to step 2.

The problem is solved.

Step 2

Replace the imaging unit, and then resend the print job.

Does fog or shading appear on prints?

Contact technical support. The problem is solved.
