network. The length of the SSID should be 1-32 characters including “_”.

 SSID Broadcast: The default setting is “Enable”.

 Wi-Fi Channel: Different domain has different channels (Channel 1~11 in FCC

(US)/IC (Canada); Channel 1~13 in ETSI (Europe); Channel 1~13 in MKK

(Japan)).

 Max Number of Users: Set the maximum number of Wi-Fi users. The default and

maximum value is “10”.

 AP Isolation: set the AP Isolation to enable or disable

6.2 WPS

WPS (Wi-Fi Protected Setup) provide a more intuitive way of wireless configuration

between your device and the wireless client. Please make sure that the client support

WPS.

 PBC(Push Button Configuration):

1, On the client (eg PC), select the Wi-Fi access utility which includes WPS

support (provided by PC vendor) and select the PBC.

2, Login web page(192.168.1.1),settings->WPS.

3, Enable PBC and click " ".

Note: If the WPS function start correctly, the info will display in the page as bellow:

"PBC operation successfully!", Else displayed "PBC operation failed" to indicate

the problem happened during the WPS setup.

 PIN:

1, On the client (eg PC), select the Wi-Fi access utility which includes WPS

support (provided by PC vendor) and select the PIN method, then a 8 digits

PIN code will be generated.

2, Login web page(192.168.1.1),settings->WPS.

3, Enable PIN and entered the 8 digits PIN code.

4, Click <Apply>.

Note: If the WPS function start correctly, the info will display in the page as bellow:

"PIN submit successfully!", else displayed" PIN submit failed!" to indicate the problem

happened during the WPS setup.

6.3 Router

DHCP:
