Alcatel ONE TOUCH LINK W800 [12/20] Language

 Router IP Address: The router's IP address on the LAN. The default setting is

“192.168.1.1”.

 Subnet Mask: The router's internal LAN subnet mask. The default setting is

“255.255.255.0”.

 Host Name: Name of web server.

 DHCP Server: DHCP Server will automatically assign IP addresses to devices on

the network. The default setting is “Enable”.

 DHCP IP Pool: Set a range of IP addresses available to access.

 DHCP Lease Time: Amount of time that a Wi-Fi enabled device can use its

assigned IP address before it is required to renew the lease.

MAC Filtering:

MAC filtering is used to control specific MAC addresses to access.

 Select “Disable" : All terminal devices are allowed to access the network.

 Select “Enable": Only devices in this list are allowed to access the network.

You can add, edit or delete the configuration.

Note: The maximum allowed MAC list is 10.

6.4 Language

Change language:

1,Choose the language, ;

2, Click <Apply>.

6.5 Admin Password:

1.Login Password: Set the password for login.

6.6 System

Reboot

Click <Reboot> to restart the device.

Reset

Reset the device to the original factory settings. you can also use the hardware reset

button under the back cover, marked with Reset.

Save the configuration

1,Click <Backup>;

2,Select the location to save current settings.
