Alcatel ONE TOUCH LINK W800 [5/20] Overview

1. Overview

This device allows you to share a secure Mobile Broadband internet connection using

Wi-Fi. You can connect most Wi-Fi enabled devices to it (for example PCs, mobile

gaming devices, Smart phones, tablet).This device should not be used in a confined

space where air flow is limited, for instance inside a jacket pocket or inside a hand bag

etc.

1.1 System Requirements

To use this device you need a device with Wi-Fi capability (supporting Wi-Fi 802.11

b/g/n) and a web browser.

1.2 Interface description

 USB description:

To provide power to this device via USB(PC,Charger or Power bank provide power)

 LED description:

LED TYPE

LED Indicator

Description (state)

Network LED

Lilac Light constant for seconds

Power supply finished

Orange Light Fast Flashing(5Hz)

Network Searching

Constant Orange Light

Out of order

Red Light Slow Flashing (1Hz)

Registering into LTE Network

Constant Red Light

Registered to LTE Network

Green Light Slow Flashing (1Hz)

Registering into 3G network

Constant Green Light

Registered to 3G network

Blue Light Slow Flashing (1Hz)

Registering into 2G network

Constant Blue Light

Registered to 2G network

WIFI LED

Constant Blue light

Wifi open

Blue Light close

Wifi close

Blue Light Slow Flashing

(Continuation 5 s)

Receive SMS
