Alcatel ONE TOUCH LINK W800 [7/20] Quick setup

Tab 2.1

ATTENTION! DATA TRAFFIC AND OTHER NOTIFICATION TEXT MESSAGES

SENT BY YOUR SERVICE PROVIDER CAN BE READ ONLY WHEN THIS PAGE

IS VISIBLE. IF YOU CLOSE OR SEND IT TO BACKGROUND YOU MAY MISS OR

BE INFORMED LATE BY YOUR IMPORTANT MESSAGES! BLINKING LED

LIGHTS ALSO INFORM YOU ABOUT INCOMING MESSAGES – PLEASE

CONSULT THE USER’S GUIDE.

3. Quick Setup

user can easily setup other function about PIN,internet,profile, WLAN etc.

4. Connection

You can move the mouse to "Connection" and click the items you want. In this section,

the following items are included:

 Connection Status: current connection, WAN status, WLAN status.

 Profile management: manage account settings, which includes your preferred

network connection as well as the Access Point Name (APN).

 Network: choose and set up preferred network settings.

 PIN management: manage PIN, enable/disable/change/verify.

 Connection Mode: Set the dial mode of this device, default is AUTO.

4.1 Connection status

Current status

 Active profile: Select the profile you want to use from the drop down box.

 Duration time: the duration for current connection.

 Roaming: display whether you are in roaming network or not.

WAN status

 Network name: the 4G/3G/2G network you used.

 Network type: GPRS/EDGE/UMTS/HSDPA/HSUPA/HSPA+/LTE.

 Rate: current download speed from 4G/3G network.

 IP address: this is the IP address arranged for this device.

WLAN status

 WLAN Status: On or Off the WLAN

 SSID: the network name of this device

 Security: the cipher type of the Wi-Fi used.

 User: the users connected to this device and max capacity .
