Stiga MULTICLIP 50 S SILENT PLUS [12/164] Components and controls

Stiga TURBO 53 4S SILENT RENTAL [12/164] Components and controls

– if you have spilt some fuel, do not attempt

to start the engine but move the machine

away from the area of spillage and avoid

creating any source of ignition until the fuel

has evaporated and fuel vapours have dis-

sipated.

– always put the tank and fuel container caps

back on and tighten well.

4) Replace faulty silencers and the guard, if

damaged.

C) OPERATION

1) Do not operate the engine in a confined

space where dangerous carbon monoxide

fumes can collect.

2) Do not use starting fluids or similar pro-

ducts.

3) Do not change the engine governor set-

tings or overspeed the engine.

4) Do not tilt the machine onto its side to pre-

vent fuel leaks from the fuel tank cap.

5) Do not touch the cylinder fins and/or the

silencer guard until the engine has cooled

down.

6) Stop the engine and disconnect the spark

plug cable before checking, cleaning or servi-

cing the machine or the engine.

7) Do not crank the engine with spark plug

removed.

8) Transport the machine with an empty fuel

tank.

D) MAINTENANCE AND STORAGE

1) A routine maintenance is essential for

safety and for keeping a high performance

level.

2) Do not store the machine with fuel in the

tank in an area where the fuel vapours could

reach an open flame, a spark or a strong heat

source.

3) Allow the engine to cool before storing in

any enclosure.

4) To reduce the fire hazard, keep the engine,

the silencer and the fuel storage area free of

grass, leaves, or excessive grease.

5) If the fuel tank has to be drained, this

should be done outdoors once the engine has

cooled down.

6) On safety ground, never use the engine

with either worn or damaged parts. Parts are

to be replaced and not repaired. Use genuine

spare parts. Parts that are not of the same

quality can damage the engine and impair

your safety.

ENGINE COMPONENTS

1. Rope handle

2. Oil fillercap with dipstick

3. Air cleaner cover

4. Silencer

5. Silencer guard

6. Spark plug cap

7. Engine code

ACCELERATOR CONTROL

The throttle trigger (generally a lever), fitted to

the machine, is connected to the engine by a

cable.

Consult the machine’s Instructions Manual to

identify the throttle trigger and its positions, usu-

ally marked by symbols, corresponding to:

CHOKE = to be used for cold starting.

FAST = corresponds to maximum revs;

to be used when working.

SLOW = slowest speed.

STOP = engine stop (if fitted).

3.2

3.1

3. COMPONENTS AND CONTROLS

Note your engine

serial number here

✍
