Knog NERD WIRELESS 9 [8/64] Button functions and normal operations

Knog NERD WIRELESS 12 [8/64] Button functions and normal operations
8
2
sec
MODE BUTTON (Fig 2.1)
Press
A
to advance from one mode display to another.
SET BUTTON
Press
B
to enter the setting screens to re-set the bike
circumference or the current time.
RESET OPERATION (Fig 2.2)
1. Hold down
A
for 3 seconds until the display digits are
cleared. The computer will reset the stored AVG, TRIP DIST,
TIMED TRIP and MAX data back to
.
A reset operation only resets the data for the currently
selected bike (
1
or
2
*) and does not reset the ODO,
T.TIMED TRIP or DIST/DAY data.
AUTO POWER OFF & STANDBY MODE
To preserve battery power, the computer will automatically
power off to standby mode after 15 minutes. Standby mode
displays only the clock. Normal operation will be returned
on by pressing
A
once whilst in standby mode.
AUTOMATIC START/STOP
The computer will automatically begin counting data upon
riding and stop counting data when riding is stopped.
In order to automatically begin counting, the computer
must not be in standby mode.
TURNING ON/OFF THE DISPLAY BACKLIGHT* (Fig 2.3)
1. To turn the backlight on, hold
A
for 6 seconds until the
display shows the
icon.
2. To turn the backlight off, repeat step 1 until the
icon
disappears.
While the backlight is active, pressing
A
once
illuminates the current mode display only—
A
must be
pressed again whilst the backlight is on to advance to the
next mode display.
Fig 2.1
SEQUENCE OF FUNCTION MODES
Fig 2.2
RESET OPERATION
2
sec
BUTTON functions and NORMAL OPERATIONS
2
sec
Fig 2.3
TURNING ON/OFF THE DISPLAY BACKLIGHT*
CLOCK TRIP DISTANCE TRIP TIME MAXIMUM SPEED AVERAGE SPEED
RESETS AVG, TRIP DIST,
TIMED TRIP, MAX
3 seconds 6 seconds 6 seconds
* = N.E.R.D Wireless 12 Function Cycle Computer only
