Knog NERD WIRELESS 9 [10/64] Bike installation

MAIN UNIT (Fig 3.1)

The main computer unit is designed with a removable and

rotatable main housing for mounting to handlebars or a

handlebar stem. The silicon strap makes the installation on

a bike super easy and fast.

1. Chose a suitable location on your handlebars (1) or

stem (2) that will enable a good line of sight down to

the transmitter and the main unit with minimal physical

obstructions.

2. Pull the silicon strap around the bars, fit it over the hook

and you’re done!

The silicon strap on the main computer is designed to

accommodate mounting diameters of 22mm up to 38mm.

For optimum wireless signal clarity your N.E.R.D. should

be positioned 5cm (2 inches) away from your white bike

light.

BIKE INSTALLATION

Fig 3.1

* = N.E.R.D Wireless 12 Function Cycle Computer only
