Alto M3 [8/10] Appendix
![Alto M3A [8/10] Appendix](/views2/1000653/page8/bg8.png)
7
APPENDIX
Part Description
Item
1
2
3
4
5
6
7
8
9
10
11
12
Exploded Diagram of The Accessory (YS-60)
Ni Screw, M6 55 1.0PH
Fixing Bracket - Left
Spring
Mounting Base
Fixing bracket - Right
Ni Nut
Fixing Lever
Zn Screw, M6 1.0PH 10
Connecting Lever
Ni Screw, M3 10
Solid Slide
Spring Washer
