TECHNICAL SPECIFICATIONS
System type
M3
M4
M5
2Way 2Way 2Way
Power Handing
SPL 1W, 1m
Frequency Response
Impedance
Crossover Frequency
Dimension HxWxD
Net Weight /kg
AES 30W
87dB
50Hz-13kHz (-10dB)
4Ohm
2.3-3kHz (at 1m/W)
216.5x143.5x152.5mm
2.4kg
AES 70W
92dB
40Hz-15kHz (-10dB)
4Ohm
2.3-3kHz (at 1m/W)
287.5x169x201mm
4.8kg
AES 80W
95dB
40Hz-15kHz (-10dB)
4Ohm
2.3-3kHz (at 1m/W)
376x223.5x267mm
6.6kg
System type
M3A
M4A
M5A
2Way 2Way 2Way
Power Handing : HF
SPL 1W, 1m
Frequency Response
Impedance
Crossover Frequency
Dimension HxWxD
Net Weight /kg
20W(EIAJ), 15W(RMS)
87dB
50Hz-13kHz (-10dB)
4Ohm
2.3-3kHz (at 1m/W)
216.5x143.5x152.5mm
3.6kg
36W(EIAJ), 30W(RMS)
92dB
40Hz-15kHz (-10dB)
4Ohm
2.3-3kHz (at 1m/W)
287.5x169x201mm
6.5kg
70W(EIAJ), 60W(RMS)
95dB
40Hz-15kHz (-10dB)
4Ohm
2.3-3kHz (at 1m/W)
376x223.5x267mm
8.3kg
38W(EIAJ), 30W(RMS)
72W(EIAJ), 60W(RMS)
142W(EIAJ), 130W(RMS)
LF
