Yamaha XJR1300 (L) (1999) [319/346] Lighting system
![Yamaha XJR1300 (L) (1999) [319/346] Lighting system](/views2/1121392/page319/bg13f.png)
7-28
LIGHTING SYSTEM
ELEC
NOTE:
YES
NO
Replace the fuse(-s).
1. Main, and headlight fuses
S Check the main, and headlight fuses for con-
tinuity.
Refer to “CHECKING THE FUSES” in chap-
ter 3.
S Are the main, and headlight fuses OK?
2. Battery
S Check the condition of the battery.
Refer to “CHECKING AND CHARGING THE
BATTERY” in chapter 3.
Open-circuit voltage
12.8 V or more at 20_C
S Is the battery OK?
YES
S Clean the battery
terminals.
S Recharge or
replace the battery.
NO
EAS00749
S Check the main switch for continuity.
Refer to “CHECKING THE SWITCHES”.
S Is the main switch OK?
YES
Replace the main
switch.
NO
3. Main switch
EAS00783
S Check the lights switch for continuity.
Refer to “CHECKING THE SWITCHES”.
S Is the lights switch OK?
YES
The lights switch is
faulty. Replace the
right handlebar
switch.
NO
4. Lights switch (for Europe)
EAS00781
TROUBLESHOOTING
Any of the following fail to light: head-
light, high beam indicator light, taillight,
auxiliary light (for Europe) or meter light.
Check:
1. main, and headlight fuses
2. battery
3. main switch
4. lights switch (for Europe)
5. dimmer switch
6. pass switch
7. wiring
(of the entire charging system)
S Before troubleshooting, remove the following
part(-s):
1) seat
2) fuel tank
3) headlight unit
S Troubleshoot with the following special
tool(-s).
Pocket tester
90890-03112
EAS00738
EAS00739
