REAR
SHOCK
ABSORBER ADJUSTMENT
By
the following adjustment steps.
Spring preload adjustment steps:
*Using the screwdriver, adjust the spring
preload.
Stiffer
Increase the spring preload.
(Turn the spring
seat
clock
-
wise.)
(Turn
the
spring
seat
counter
-
clockwise.)
Softer
Decrease the spring preload.
A Position:
5
(Maximum)
4
3
2
1
(Minimum/Standard)
Standard Position (Minimum Position):
Maximum Position:
1
5
Never attempt to turn the spring
seat
beyond
the maximum or minimum setting.
Damping adjustment steps:
the damping with the damping
adjuster
.
Stiffer Increase the damping.
(Turn the adjuster
clockwise.)
Decrease bhe damping
(Turn the adjuster
counter
-
clockwise.)
Standard Position (Minimum Position):
Maximum Position:
1
4
Never attempt to turn
the
adjuster beyond
the maximum or minimum
setting.
2
-
