FRONTFORK
D
LY
bolt
1.
Remove:
Use the Front Fork Cap Socket
01
104).
Spring
seat
Fork spring
Inner fork tube
2. Remove:
Dust cover
Retaining clip
Use
a
thin screwdriver, and be careful not
t o scratch the inner fork tube.
3. Remove:
Bolt (cylinder complete)
Use the Damper Rod Holder
t o lock the damper rod.
and the T
-
Handle
4.
Remove:
Damper rod (cylinder complete)
Rebound spring
5.
Remove:
Inner fork tube
By the following removal steps.
inner fork
tube
removal
steps:
Hold fork
leg
horizontally.
the caliper mounting bossof the outer
tube securely in
a
vise
with soft jaws.
out the inner fork tube from the outer
tube by forcefully, but carefully, with draw
-
ing the inner tube.
6
-
29
