Konica Minolta bizhub 160f [254/302] Caution

When a message appears

8-10 bizhub 160f

7 CAUTION

Incorrect handling of image cartridge.

% Do not push in the imaging cartridge with excessive force if the car-

tridge is not correctly aligned on the rail, otherwise the units may be

damaged.

8 Align the tab on the imaging car-

tridge with the rail in the machine,

and then install the cartridge.

9 Close the front cover.
