When a message appears

8-16 bizhub 160f

3 Remove all paper from tray 1. Do not

reuse paper that has been misfed.

4 Reload the paper stack in the tray.

5 Attach the tray removed in step 2.

6 Reload the paper removed in step 1.

7 Remove the cover of optional tray 2,

and then pull out the drawer.

8 Remove all paper from the drawer.

9 Reload the paper stack into the

drawer, and then slide the drawer

back into the paper feed cassette.
