2
Precautions for installation and use
2-6 bizhub PRO 920 Additional Information
2.3 Finisher FS-509 (+ Punch kit PK-504/505)
2
Reminder
Primary (main) tray of Finisher FS-509 gradually goes down while printed
materials output. DO NOT allow any object to interfere with the operation
of the tray on the left side of the finisher, as any interference may cause
damage to the finisher.
No. Name Description
1 Finisher door Opens to the internal finisher to allow replenishing
staples and clearing mishandled paper, and also to
allow removal of waste paper punched out when
Punch kit PK-504/505 is installed.
2 Primary (main) tray Holds sets output in the selected finishing mode
other than specified above.
3 Secondary (sub) tray Holds sets output in Sort, Group, Face Up, or Face
Down mode.
1
2
3
