1139O0040A
EP1080
1139O0170A
Holds up to 50 sheets of special
or standard paper which is not
loaded in any of the Drawers,
allowing you to make copies on
them.
➭
p. 63
◆
Multi Bypass
Table MB-1
<Option>
MB-1
◆
Paper Feed Cabinet PF-201 <Option>
Equipped with two paper Drawers to
hold up to 1,000 sheets of copy paper
(80 g/m
2
).
When equipped with Duplex Unit AD-3,
it permits the copier to offer 2-sided
copying capability.
➭
p. 68
PF-201
1139O0180A
1139O0010A
◆
Duplexing Document Feeder AFR-7
<Option>
In addition to the function of AF-3, it
can turn over 2-sided originals.
➭
p. 40
AFR-7
◆
EP1080
Equipped with two Paper Drawers to hold up to 500
sheets of copy paper (80 g/m
2
). The Manual Bypass
Table allows you to make a copy on paper which is
not loaded in any of the Drawers and which is fed into
the copier manually via this Table.
➭
p. 62
1. System Overview
Chapter 2
First Things to Know about EP1080
9
