Chapter 4 Special Function 89
1. Checking The Total Number Of Copies
Mode 90
2. Auxiliary Toner Replenishing Mode
(Increasing the Image Density) 92
3. Drum Dehumidify Function 93
4. User’s Choice 94
Chapter 5 When an Indicator
Lights Up 107
(Replenishing Supplies, Clearing Misfeed,
and Correcting a Closure Failure)
1. Quick Reference for Indicator Lights 108
2. Detailed Instruction for Indicator Lights
Add Toner Indicator 110
Add Paper Indicator 112
Add Staple Indicator 116
I. U. Service Life Indicator 120
Closure Failure Indicator 130
Misfeed Indicator
• Misfeed Indicator and Monitor Display 132
• Misfeed Clearing Procedure
: Copier EP1080 134
: Paper Feed Cabinet PF-201 140
: Duplex Unit AD-3 142
: Duplexing Document Feeder AFR-7 146
: Automatic Document Feeder AF-3 147
: Sorter/Staple Sorter S-104/ST-101 148
Call-Tech.-Rep. Indicator 149
