Konica Minolta EP1080 [4/197] Chapter 3 making copies 35
![Konica Minolta EP1080 [4/197] Chapter 3 making copies 35](/views2/1122098/page4/bg4.png)
Chapter 3 Making Copies 35
1. Basic Copying Overview 36
2. Basic Job Setting
Original Placement 38
Using Automatic/Duplexing Document Feeder
(AF-3/AFR-7) 40
Image Density 46
Zoom Ratio
• Types of Zoom Ratio 48
• Auto Size Mode 51
• Zoom Ratio Table
(Orignal Size to Paper Size) 53
Paper Size
• Manual Mode 54
• Auto Paper Mode 56
Number of Copies 58
Copy Cycle Start 59
Interrupt Mode 60
Manual Bypass Copying 62
3. System Copying Overview 64
Typical Job Setting Procedures 66
4. System Job Setting
Job Type
• Available Job Types 68
• Precaution for Original Loading 72
Finishing Mode
• Finishing Modes 74
• Auto Dual Function 76
• When the Number of Copies Set to be Made Exceeds 25 in
the Group Mode 77
• If the Number of Copies Set to be Made Exceeds 50 in the
Non-Sort Mode 77
• Selecting the Finishing Mode 78
• Precautions for Original Loading for Copies Stapled
Automatically or Manually 80
• Typical Finishing Modes 82
File Margin Mode 84
Cover Mode 86
Job Memory 88
Contents
iv
