Chapter Overview
Operation Panel with LCD Display
}
— Access telephone
book functions
Red lamp
v
—If the lamp
fl ashes, please read what is indi-
cated on the display
¾
— Select options / Move
the cursor on the display
¨
—Print list of functions, jobs,
settings / Start quick install /
Print out fax journal or tele-
phone book
MENU/OK—
Access functions /
Confi rm inpu
t
MODE—Fax reception mode
Manual, Fax, EXT/ANSW.,
COPY—Press twice: Make copies
automatically. Press once: Modify copies
STOP—Interrupt an ongoing opera-
tion without saving / Eject document
START—Start a fax transmission or
fax reception
h
/
f
/
F
—Set resolution (NORMAL,
FINE—
h
, SFINE—
f
, PHOTO—
F
)
C—Delete / One menu step back
W
— Read, edit or send SMS mes-
sages
º
—List of the last ten numbers
dialled
Blue key and
º
—List of last ten
callers
R/PAUSE
—Access special functions
Blue key and R/PAUSE—Insert dial-
ling pause
¼
—Listening during dialing
Blue key and
¼
—Attach addi-
tional entry to a fax broadcast
Press the blue key and the correspond-
ing letter key to enter the symbols
shown above it
Symbols on the LCD Display
f
— SFINE resolution confi gured
F
— PHOTO resolution confi gured
h
— FINE resolution confi gured
I
— Incoming calls during absence
W
— Incoming SMS messages
Green Lamp
»
—It fl ash-
es whenever an SMS message
has arrived or when a docu-
ment is waiting to be retrieved
from the fax memory
7
