Konica Minolta bizhub C754 [132/284] In windows xp server 2003
![Konica Minolta bizhub C754 [132/284] In windows xp server 2003](/views2/1122312/page132/bg84.png)
Appendix: Manual installation process of the printer driver
2
2-116 bizhub C754/C654
2.8
18 Follow the instructions on the pages that follow.
% If the [User Account Control] window appears, click [Continue] or [Yes].
19 Click [Finish].
20 After finishing the installation, make sure that the icon for the installed printer is displayed in the [Print-
ers] or [Devices and Printers] window.
21 Remove the DVD-ROM from the DVD-ROM drive.
This completes the installation process of the printer driver.
In Windows XP/Server 2003
0 Administrator privileges are required to perform this task.
1 Insert the DVD-ROM into the DVD-ROM drive of the computer.
2 From the Start menu, click [Printers and Faxes].
% If [Printers and Faxes] is not displayed, select [Control Panel] - [Printers and Other Hardware] -
[Printers and Faxes] from the Start menu.
3 Select Printer Install.
% In Windows XP, select [Add a printer] from [Printer Tasks].
% In Windows Server 2003, double-click [Add Printer].
[Add Printer Wizard] appears.
4 Click [Next >].
5 Select [Local printer attached to this computer], then click [Next >].
% Clear the [Automatically detect and install my Plug and Play printer] check box.
The [Select a Printer Port] page appears.
6 Click [Create a new port:], then select [Standard TCP/IP Port] as the [Type of port:].
7 Click [Next >].
[Add Standard TCP/IP Printer Port Wizard] starts.
8 Click [Next >].
9 In the [Printer Name or IP Address:] box, enter the IP address for the machine, and then click [Next >].
% If the [Additional Port Information Required] dialog box appears, go to Step 10.
% If the [Finish] screen appears, go to Step 13.
10 Select the [Custom] check box, then click [Settings:].
11 Change the settings according to the port, and then click [OK].
% For an LPR connection, select the [LPR] check box, then enter "Print" in [Queue Name:]. You must
discriminate between upper and lower case letters when entering it.
% For Port 9100 connection, select the [Raw] check box, and then enter a RAW port number (initial
setting: [9100]) in [Port Number:].
12 Click [Next >].
13 Click [Finish].
[Add Printer Wizard] appears.
14 Click [Have Disk...].
15 Click [Browse...].
