Konica Minolta bizhub C754 [61/284] Creating an overlay image in the computer

bizhub C754/C654 2-45

2.4 Useful printing functions

Creating an overlay image in the computer

In your computer, you can create an image that is composed on the original from [Overlay] in the

[Stamp/Composition] tab. For example, you can register a corporate letterhead or other forms for use as a

composite image on the original.

1 In application software, create an original to be registered in an overlay image.

2 In [Overlay] in the [Stamp/Composition] tab, select [Create Host Image].

3 In the application software, execute printing.

The [Create Overlay File] window appears.

4 Enter the file name and save the file.

The overlay image is saved on your computer. From then on, when you select [Print Host Image] in

[Overlay] in the [Stamp/Composition] tab, the saved overlay image is displayed in the list and is also

available.

Settings Description

[Obtain Device Information] If your computer can communicate with this machine, your computer ob-

tains and displays the latest information on the overlay images registered

in this machine.

[Overlay Info] Information on the overlay image selected from the list is displayed.

[Print on Front Side]/[Print

on Back Side]

Select this check box to compose an overlay image on the front and back

sides. In addition, specify how to compose an overlay image.

• [Overlay Name]: Select the overlay image to be composed.

• [Select color]: Select the color of the overlay image to be composed.

• [Density]: Specify the density of the overlay image to be composed.

• [Overwrite]: Select whether to compose the overlay image by overwrit-

ing the image on the front side of the original, or to compose it on the

back side of the original by watermarking the image.

• [Same as Front Side]: Select this check box to apply the settings for

the front side to the back side.

[Pages] Select the range of pages on which an overlay image is composed.
