Appendix: Using this machine with other connection methods

3-86 bizhub C754/C654

3.7

In Mac OS X 10.2/10.3

In Mac OS X 10.2/10.3, use the following procedure to add a printer with an LPR connection:

1 Select [System Preferences...] in the Apple menu.

2 Click the [Network] icon.

3 From [Show], select [Built-in Ethernet].

4 Click the [TCP/IP] tab.

5 Select the [Settings:] item and configure the settings including the IP address and subnet mask accord-

ing to the settings for the network to which the computer is connected.

6 Click the close button at the top left corner of the window.

% When the [Apply configuration changes] message appears, click [Apply].

Then, add the printer to the computer.

7 From [Macintosh HD] - [Applications] - [Utilities], double-click [Printer Setup Utility] or [Print Center] to

open it.

8 When the [You have no printers available.] window appears, click [Add]. When the printer list appears,

click [Add].

% If available printers have already been specified, the [You have no printers available.] window does

not appear.

9 Select [IP Printing] as the connection method.

10 In Mac OS X 10.3, select [LPD/LPR] in [Printer Type:].

11 In [Printer Address:], enter the IP address for the machine.

12 In [Printer Model:], select [KONICA MINOLTA], then click the driver of the desired printer from the model

list.

13 Click [Add].

This completes the addition process of the printer. Then, proceed to the [Installable Options] window

to configure the optional environment for this machine. For details, refer to page 3-7.
