29
INSTRUCTION MANUAL
11.3.20. ¬ ODO BIKE 2 = total distance bike 2
Shows the total of all distances ridden with bike 2 in km or mi (auto-
matic conversion of all values when switching to mi)
Display √ ODO BIKE 2
Maximum value: 99,999 km or mi
11.3.21. ¬ ODOTOTAL = total distance bike 1 and bike 2
Shows the total of all distances ridden with bike 1 and bike 2 in km or
mi (automatic conversion of all values when switching to mi)
Display √ ODOTOTAL
Maximum value 199,999 km or mi
11.3.22. ¬ TIME BIKE 1 = total time bike 1
Shows the total time of all day trips ridden with bike 1 in hhh:mm
Display √ TIME BIKE 1
Maximum value 999:59 hhh:mm
11.3.23. ¬ TIME BIKE 2 = total ride time bike 2
Shows the total time of all day trips ridden with Bike 2 in hhh:mm
Display √ TIME BIKE 2
Maximum value 999:59 hhh:mm
11.3.24. ¬ TOTAL TIME = total ride time bike 1 and bike 2
Shows the total time of all day trips ridden with bike 1 and bike 2 in
hhhh:mm
Display √ TOTAL TIME
Maximum value: 1999:59 hhhh:mm
HEART RATE FUNCTIONS (button ≈ )
PLEASE NOTE: All heart rate functions with the exception of „actual
heart rate“ display require a running stopwatch or a running timer.
11.3.25. ¬ £ STOPWATCH = manual stopwatch
Prerequisite: Only after selecting stopwatch, chapter 13.1.
Display ≈ STOPWATCH
Start measuring ∫ Press
Stop measuring ∫ Press
Display pulse data ≈ LIMIT LO HI (values run sequen-
tially, automatically in 2 second
rhythm)
Reset: ∫ Press button for 4 sec.
Compare chapter 14. Training with recording of the residence times in
the pulse ranges
11.3.26. ¬ £ TIMER = timer 1 / timer 2 / timer 1+2
Prerequisite: Only after selecting timer, chapter.
13.1.
Display ≈
Start measuring ∫ Press
End of measurement Automatic after timer period
elapses (or number of sequen-
ces for timer 1+2), beeper
signal
Display pulse data ≈ LIMIT LO HI (values run sequen-
tially, automatically in 2 second
rhythm)
