9
INSTRUCTION MANUAL
1.3.2. SETTING MODE - use this mode to make all settings. The assignment of buttons is on the buttons
To go to setting mode: Press button ç for 3 seconds
SETTING MODE
Z3 PC-LINK
or
Chap. 8.1.
Chap. 8.2.
Chap. 8.3.
Chap. 8.4.
Chap. 6.1.
Chap. 10.
Chap. 5.4.
Chap. 7.5.
Chap. 3.3.
Chap. 15.1.
LANGUAGE SELECT
NAVIGATOR SET
WHEELSIZE SET
WHEELSIZE CHANGE
CLOCK SET
ALARM SET
TIMER SETTINGS
ODOMETER SET
PULSE LIMIT SETTINGS
RECOVERY SET
Chap. 4.1.
Chap. 12.1.
Chap. 5.1.
Chap. 5.2.
Chap. 4.2.
Chap. 4.3.
Chap. 13.1.
Chap. 5.3.
Chap. 7.1.
Chap. 7.4.
HOME ALTI SET
ACTUAL ALTI SET
ALTI UP SET
ALTI DOWN SET
PERSON DATA SET
OP MODE SELECT
BIKE CHECK SET
POWER CALC SET
DIG-CONNECT SET
PC LINK SELECT
å (Once) = last step, or back one menu level
(Hold) = return to start menu
‚: Select/confi rm displayed option
In the highest menu level select the next menu level
Page down within the menu level
∂ In SET mode (number fl ashes): Reduce number
Page up within the menu level
ƒ: In SET mode (number fl ashes): Increase number
After subsequent confi rmation of a setting the computer automatically returns
to operation mode.
