Asko D5436 S [18/24] Warning
![Asko D5436 W [18/24] Warning](/views2/1124904/page18/bg12.png)
Installation
519
1189
550
30-94
596
30
670
49
700
717
821 -872
133-183
[mm]
*Remove locking nuts for an installed height of
820-821 mm.
Safety instructions
• Connections to electricity, water and drainage must be per-
formed by a qualified professional.
•
• Always follow applicable regulations for water, drainage and
electricity.
• An incorrect or flawed installation can result in higher consump-
tion of energy, water and detergent, which can result in in-
creased costs and poor dishwashing results. In order to min-
imise noise it is important that you follow the instructions.
• Take care during installation! Wear protective gloves! There
must always be two people!
• Before screwing the dishwasher into place, test the dishwasher
by running the Rinse & Hold program. Check that the dish-
washer fills with water and drains. Check also that none of the
connections leak.
WARNING!
Turn off the water supply when installing the dishwasher!
WARNING!
The plug must be disconnected or power to the socket turned
off while the work is carried out!
Transport protection for the door
Do not forget to remove the transport protection for the door when
unpacking the dishwasher.
2x
18
