Configuration
D-Link DPH-300S User Manual
14
• Type
admin
in the User Name field
• Type
admin
in the Password field
• Click OK
If you get a Page Cannot be Displayed error, please refer to
the Troubleshooting section for assistance.
The Home > Wizard screen will appear. Please refer to the
Quick Installation Guide for more information regarding the
Setup Wizard.
