Section 1 - Product Overview
D-Link DPH-300S User Manual
8
Hardware Overview
Connections
Reset button
To manually reset, depress
button with the power on for at
least seven seconds
LAN 1 Port
Connect the Ethernet cable from a
computer on your LAN to this port.
LAN 2 Port
Connect the Ethernet cable from
your Cable/DSL modem to this port.
Power Adapter
Connect your 12V DC, 1.25A power
adapter here.
Phone Connection
Connect to your phones using
standard phone cabling.
