Section 1 - Product Overview
D-Link DPH-300S User Manual
2
Package Contents
• D-Link DPH-300S Cordless IP Telephone
• D-Link DPH-300S Cordless IP Telephone Connector Base
• Power Adapter 12V DC, 1.25 A
• Manual and Warranty on CD
• Quick Installation Guide
• Ethernet Cable (the DPH-300S’s Ethernet port is Auto-MDIX)
Note: Using a power supply with a different voltage rating than the one included
with the DPH-300S will cause damage and void the warranty for this product.
System Requirements
• Broadband Internet connection
• Ethernet-Based Cable or DSL Modem
• A multi-port Ethernet router (possibly integrated as part of the Cable or DSL Modem listed above).
• 100Mbps of available Internet bandwidth
• Computer with Windows, Macintosh, or Linux-based operating system and an installed Ethernet adapter
• Internet Explorer Version 6.0 or Netscape Navigator Version 6.0 and Above
