Assembly

1. Attach two Adjustable Foot Plate (#24) to the Weight stack Frame (#1).

2. Attach the Adjustable Foot Plate (#24) to the Bottom Cross Brace (#2).

3. Attach Bottom Cross Brace (#2) to the Weight stack Frame (#1) using:

● two M10*100 HHB (#58)

● four Φ11*Φ20*2 Flat Washer (#73)

● two M10 Nut Nylon Lock (#76)

4. Attach the Upright Frame (#3) to the Bottom Cross Brace (#2) using:

● two M10*70 HHB (#60)

● two Φ11*Φ20*2 Flat Washer (#73)

5. Attach the Top Cross Brace (#4) to the Upright Frame (#3) using:

● three M10*80 HHB (#59)

● six Φ11*Φ20*2 Flat Washer (#73)

● three M10 Nylon Lock Nut (#76)

6. Attach the Top Cross Brace (#4) the Weight stack Frame (#1) using:

● two M10*130 HHB (#57)

● four Φ11*Φ20*2 Flat Washer (#73)

● two M10 Nylon Lock Nut (#76)

Note: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled.

STEP 2

1. Attach two Adjustable Cross Brace (#5), One Right Cam (#6), One Left Cam (#7) to

the Top Cross Brace (#4).

2. Attach the Top Frame (#12) to the Top Cross Brace (#4) using:

● three M10*30 HHB (#62)

● three Φ11*Φ20*2 Flat Washer (#73)

● three Φ11*Φ30*2 Flat Washer (#75)

3. Attach the Right Rotary Arm (#8) to the Adjustable Cross Brace (#5) using:

● one M10*95 HHB (#63)

● two Φ11*Φ20*2 Flat Washer (#73)

● one Φ19.1*Φ10*67 Pivot Axle (#14)

● one M10 Nylon Lock Nut (#76)

4. Attach the Left Rotary Arm (#9) to the Adjustable Cross Brace (#5) using:

● one M10*95 HHB (#63)

● two Φ11*Φ20*2 Flat Washer (#73)

● one Φ19.1*Φ10*67 Pivot Axle (#14)

● one M10 Nylon Lock Nut (#76)

Note: Wrench Tighten Bolts and Nylon Lock nuts.

STEP 1
