Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

57 Hex Head Bolt M10*130 3 79 Hex Flanged Nut 2

58 Hex Head Bolt M10*100 2 80 Socket Set Screw 10-32*3.2 8

59 Hex Head Bolt M10*80 3 81 Spacer 4

60 Hex Head Bolt M10*70 2 82 Hex Key s=3 1

61 Hex Head Bolt M10*50 1 83 Hex Key s=4 1

62 Hex Head Bolt M10*30 3 84 Hex Key s=5 1

63 Hex Head Bolt M10*95 2 85 Hex Key s=6 1

64 Button Head Cap Screw M8*55 1 86 Hex Key s=8 1

65 Button Head Cap Screw M6*12 2 87 Hex Key s=3/32" 1

Socket Head Cap Screw M10*50

2 88 Wrench 1

67 Socket Head Cap Screw M8*30 1 89 Hex Head Bolt M10*35 4

68 Socket Head Cap Screw M8*20 4 93 Lube 1

69 Socket Head Cap Screw M4*15 2 94 Nut 4

70 Flat Head Cap Screw M10*30 4 95 Rear Shroud 1

71 Philips Screw M5*12 5 98 Front Shroud 1

72 Rivet Nut M5 1 100 Rubber Plug 2

73 Flat Washer Φ11*Φ20*2 31 101 Spring Washer 2

74 Flat Washer Φ9*Φ16*1.6 6 102 Hex Head Bolt M8*30 2

75 Flat Washer Φ11*Φ30*2 3 103 Rivet Nut 2

76 Nylon Lock Nut M10 13 106 Weight Stack Space 2

77 Nylon Lock Nut M8 5 108 Flat WasherΦ9*Φ22*1.6 2

78 Hex Nut M6 2 111 Socket Set Screw M6*15 2
