Assembly

Step 3

1. Attach Linear Shaft (#32) to Right and Left Frame (#3,#4) then install 2

Aluminium Pillow Block Bearing (#31) onto each Linear Shaft (#32), secure

the Linear Shaft (#32) to Right and Left Frame (#3,#4) using:

two 5/16"-18*115 HHB (#70) two Φ8.5*Φ22*2 Washer (#71)

two Φ10*Φ13*2 Spacer(#33) two Φ38 Plug (#68)

2. Attach Carriage (#5) to Aluminium Pillow Block Bearing (#31) using (If

necessary take off Stop Beam (#29) ):

eight 3/8"-16*16 HHB (#73) eight 3/8" Spring Washer (#72)

3. Complete underside of Carriage (#5) assembly using:

one Weight Holder (#7) one Connecting Tube (#6)

four M12*75 BHCS (#56) three Φ13*Φ24*1.5 Washer (#49)

three M12 Nylon Lock Nut (#61) two M10*75 BHCS (#55)

sixΦ11*Φ20*2 Washer (#48) four M10 Nylon Lock Nut (#60)

fourΦ13*Φ38*2 Washer (#67) two Φ11*Φ38*2 Washer (#66)

one Small Foot Plate (#8) two M10*60 BHCS (#54)

4. Attach Left and Right Handle Bars (#10,11) to Carriage (#5) using:

two M10*75 BHCS (#55) four Φ11*Φ20*2 Washer (#48)

two M10*25 BHCS (#53) two Φ11*Φ38*2 Washer (#66)

two M10 Nylon Lock Nut (#60)

NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
