- 8
Only use accessories and spare parts
which have been approved by the man-
ufacturer. The exclusive use of original
accessories and original spare parts
ensures that the appliance can be oper-
ated safely and troublefree.
At the end of the operating instructions
you will find a selected list of spare
parts that are often required.
For additional information about spare
parts, please go to the Service section
at www.kaercher.com.
The warranty terms published by the rele-
vant sales company are applicable in each
country. We will repair potential failures of
your appliance within the warranty period
free of charge, provided that such failure is
caused by faulty material or defects in man-
ufacturing. In the event of a warranty claim
please contact your dealer or the nearest
authorized Customer Service centre.
Please submit the proof of purchase.
We hereby declare that the machine de-
scribed below complies with the relevant
basic safety and health requirements of the
EU Directives, both in its basic design and
construction as well as in the version put
into circulation by us. This declaration shall
cease to be valid if the machine is modified
without our prior approval.
The undersigned act on behalf and under
the power of attorney of the company man-
agement.
Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Specifications
Power
Nominal voltage V36
Battery capacity Ah (5h) 105
Average power consumption W 1475
Drive motor output (rated output) W 560
Brushes
Working width mm 800
Broad roller brush mm 710
Diameter of roller brush mm 100
Speed of roller brushes 1/min 1750
Output of roller brush drive W570
Diameter of side-brush mm 300
Speed of side brush 1/min 85
Output of side-brush drive W32
Vacuuming
Cleaning power, air quantity l/s 45
Cleaning power, negative pressure kPa 4,0
Suction engine output W550
Volume of filter bag l35
Dimensions and weights
Drive speed (max.) km/h 5,6
Climbing capability (max.) %10
Theoretical surface cleaning performance m
2
/h 3270
Length mm 1330
Width mm 927
Height mm 1285
Permissible overall weight kg 451
Transport weight kg 376
Surface load kPa 544
Values determined as per EN 60335-2-72
Vibration total value on arms m/s
2
<2,5
Vibration total value on feet m/s
2
<2,5
Uncertainty K m/s
2
0,5
Sound pressure level L
pA
dB(A) 62
Spare parts
Warranty
CE declaration
Product: Brush vacuum cleaner for
carpets
Type: 1.011-xxx
Relevant EU Directives
2006/42/EC (+2009/127/EC)
2004/108/EC
Applied harmonized standards
EN 55014–1: 2006
EN 55014–2: 1997 + A1: 2001
EN 60335–1
EN 60335–2–29
EN 60335–2–72
EN 61000–3–2: 2006 + A2: 2009
EN 61000–3–3: 2008
EN 62233: 2008
Applied national standards
-
CEO
Head of Approbation
18 EN
