D-Link DSL-500G [3/49] Create alg

14.l2tp Layer 2 Tunneling Protocol

15.nat NAT Commands

16.pfraw PFRAW Commands

17.ppe PPPOE Commands

18.ppp PPP Commands

19.rip RIP Commands

20.snmp SNMP Commands

21.sntp SNTP Commands

22.usb USB commands

23.user System User Configuration

create alg :

1.port ALG port

create alg port:

1.portno <decvalue> Alg port

2.[ prot <ProtType> ] Values: any|tcp|udp|[num <decvalue>]

3.algtype <AlgTypes> Values: as given below

create arp :

1.macaddr <xx:xx:xx:xx:xx:xx> Physical address(Hex Format)

2.ip <ddd.ddd.ddd.ddd> IP Address

create atm :

1. port ATM Virtual Port table

2. trfdesc ATM Traffic Descriptor Table

3. vc ATM Virtual Circuit Commands

4. svccfg ATM SVC Config Commands

5. uni ATM UNI Config Commands

create atm port :

1. [ Enable|Disable ] Admin Status of the interface

2. ifname <name> Interface Name

3. [ fast|interleaved ] DSL Channel In Use

4. [ maxvc <decvalue> ] Maximum Number of VCCS

5. [ oamsrc 0x<hexvalue> ] OAM Loopback Source Id

6. [ gfrpriority 1|2|3|4|5 ] GFR priority

7. [ ubrpriority 1|2|3|4|5 ] UBR priority

8. [ cbrpriority 1|2|3|4|5 ] CBR priority

9. [ rtvbrpriority 1|2|3|4|5 ] RT_VBR priority

10. [ nrtvbrpriority 1|2|3|4|5 ] NRT_VBR priority

create atm trfdesc :

1. trfindex <decvalue> Index to traffic descriptor table

2. [ NOCLP_NOSCR | CLP_NOTAG_MCR | ] [NOCLP_SCR] Traffic Type

3. [ UBR|GFR|CBR|RTVBR|NRTVBR ] Service Category

4. [ pcr <decvalue> ] Peak Cell Rate
