D-Link DSL-500G [9/49] Create ipoa map

2.ip <ddd.ddd.ddd.ddd> IP Address of the IPoA Interface

3.mask <ddd.ddd.ddd.ddd> Network Mask

4.[ type 1577|non1577 ] Type of IPoA interface

5.[ inside|outside|none ] NAT Direction

6.[ ipftype public|private|dmz ] IP Filter Interface Type

7.[ gwy <ddd.ddd.ddd.ddd> ] Gateway IP Address

8.[ droute true|false ] Default route

9.[ usedhcp true|false ] Use DHCP

create ipoa map:

1.ifname <name> Interface Name

2.lowif <name> Physical interface name

create l2tp :

1.tunnel L2TP Tunnel Command

create l2tp tunnel:

1.config L2TP Tunnel Config

create l2tp tunnel config:

1. ifname <name> L2TP Interface Name

2.[ authtype <options> ] Values:simple|challenge|none

3.[ secret 0x<hexvalue> ] Secret

4.[ hellointerval <decValue> ] Hello Interval

5.[ idletimeout <options> ] Values:infinite|{num <decValue>}

6.[ crws <decValue> ] Control channel receive window size

7.[ maxretx <decValue> ] Number of retransmissions

8.[ maxretxtimeout <decValue> ] Maximum retransmission timeout interval

9.[ payloadseq never|always ] Payload pkts requested with seq number

10.[ transport udpip ] Underlying transport media

11.[ initiator local|remote ] Tunnel will be initiated locally or not

12.localip <ddd.ddd.ddd.ddd> Address of the local endpoint of tunnel

13.remoteip <ddd.ddd.ddd.ddd> Address of the remote endpoint of tunnel

14.[ start|stop ] Action to be taken for the tunnel

15.localhostname <name> Name of the local End-point of tunnel

16.remotehostname <name> Name of the remote End-point of tunnel

17.[ enable|disable ] Admin status

create nat :

1.rule NAT Rule Commands

create nat rule:

1.entry NAT Rule Table
