Smartphone mirroring by HDMI

This unit is equipped with an HDMI input for connection with smartphones, DVBT-2 receivers, media players

and any devices with HDMI output.

CONNECTION WITH ANDROID PHONE (MHL)

Connect any Android phone with MHL (Mobile High Definition Link) support. You need to have an MHL

adaptor (not included). After connection, the sound and image of the phone will be mirrored on the screen of

the unit, so that you can display the cellphone and make use of its resources such as navigation, photo/video

sharing and presentation.

CONNECTION WITH IPHONE (4S OR LATER)

Connect your iPhone with HDMI output capability. You need to have an HDMI adaptor (not included). After

connection, the sound and image of the iPhone will be mirrored on the screen of the unit, so that you can

display the iPhone and make use of its resources such as navigation, photo/video sharing and presentation.

To determine if your smartphone supports MHL, please check your phone’s specifications for MHL

connectivity. See the list of supported smartphones below.

The unit only works with original iPod 30 pin to HDMI (for iPhone 4S), or Lightning to HDMI adaptor (for

iPhone 5 and later). Using generic adaptors may not be compatible with our product and may produce no

image and sound.

List of Android Smartphone’s with MHL support

At the time of unit manufacture the following smartphones of major brands support the MHL function

(please check your phone specifications if you cannot find it in the list):

SAMSUNG

Galaxy Note 3, Galaxy Tab 3 8”, 10.1”, Galaxy S4, S4 Active, S4 Zoom, Galaxy Mega 6.3/5.8

Galaxy Note 8, Galaxy Express, Galaxy Note II, Galaxy S III, Galaxy Nexus 2, Galaxy Note 5.3”, Captivate

Glide, Epic 4G Touch, Galaxy S II
