Panasonic WV-SF332 [26/44] When using poe ieee802 af compliant

Important:

 • Besuretousethepowercordplugprovidedwiththisproduct.

 • Besuretofullyinsertthepowercordplugintothe12VDCpowersupplyterminal(accessory).

Otherwise, it may damage the camera or cause malfunction.

 • BesuretouseanACadaptor compliant with the Specifications regarding power source and

power consumption (☞ page 39).

t Run the 12 V DC output cable through the gap of the cable hook.

12V=IN

12 V DC output cable

Cable hook

When using PoE (IEEE802.3af compliant)

Connect a LAN cable (category 5 or better, straight, STP*) between a PoE device (such as a hub)

and the network connector of the camera.

* PAL models only

Important:

 • Useall4pairs(8pins)oftheLAN cable.

 • Themaximumcablelengthis100m{328'}.

 • MakesurethatthePoEdeviceinuseiscompliantwithIEEE802.3afstandard.

 • Whenconnectingboththe12VDCpowersupplyandthePoEdeviceforpowersupply,PoE

will be used for power supply.

 • Whendisconnecting theLAN cableonce, reconnectthecable afterabout 2seconds. When

the cable is quickly connected, the power may not be supplied from the PoE device.
