Philips FC9174 [8/132] Adjusting suction power

, The brush strip for cleaning hard oors comes out of the housing. At the same time, the

wheel is lifted to prevent scratching and to increase manoeuvrability.

3 To clean carpets, push the rocker switch again (Fig. 9).

, The brush strip disappears into the nozzle housing and the wheel is lowered automatically.



1 Connect the crevice tool (1), the small nozzle (2) or the small brush (3) directly to the

handgrip of the hose or to the tube. Use the same method as for the tube. (Fig. 10)



1 Snap the accessory holder onto the handgrip (Fig. 11).

2 Snap two accessories into the accessory holder:

- Crevice tool and small nozzle (Fig. 12).

Note: Make sure the suction opening of the small nozzle points away from the holder.

- Crevice tool and small nozzle (Fig. 13).

Note: Make sure the suction opening of the small brush points towards the holder.



1 Remove the battery compartment cover.

2 Place the batteries in the battery compartment (Fig. 14).

Make sure the - and + poles point in the right direction.

3 Reattach the battery compartment cover



1 Pull the cord out of the appliance and put the mains plug in the wall socket.

2 Press the on/off button on top of the appliance with your foot to switch on the

appliance (Fig. 15).



During vacuuming, you can adjust the suction power.

- Use maximum suction power to vacuum very dirty carpets and hard oors.

- Use minimum suction power to vacuum curtains, table carpets, etc.



With the infrared remote control, you can set the suction power to one of 5 different suction

power settings. When you switch on the appliance, it always starts running at the highest suction

power setting.

- To reduce the suction power by one setting, press the - button (Fig. 16).

- To increase the suction power by one setting, press the + button (Fig. 17).



- During vacuum cleaning, you can adjust the suction power with the suction power knob on top

of the appliance (Fig. 18)



1 If you want to pause for a moment, insert the ridge on the nozzle into the parking slot to

park the tube in a convenient position (Fig. 19).

8
