WINDING THE BOBBIN

1. Place a spool of thread on the spool pin, and secure it with

the spool pin cap. Pull the thread out from the spool and

place it through thread guides as shown in illustration.

2. Put end of thread through the hole in bobbin as shown.

3. Push bobbin winder shaft to far left position, if it is not

already there. Place bobbin onto shaft with end of thread

coming from top of bobbin. Push bobbin winder shaft to the

right until it clicks. Hold onto end of thread.

4. Start machine. Bobbin will automatically stop turning when

completely lled. Push shaft to the left to remove bobbin

and cut thread.

Be sure to use Class 15 J bobbins.
