Philips Avent SCD 525 [9/272] Parent unit

2 Insert four non-rechargeable batteries (Fig. 4).

Note: Make sure the + and - poles point in the right direction.

3 Reattach the lid. (Fig. 5)

Note: When the batteries are low, the battery light on the baby unit ashes red.

Parent unit

Operation on rechargeable batteries

The parent unit comes with two rechargeable NiMH AAA 850mAh batteries.

Charge the parent unit before you use it for the rst time or when the parent unit indicates that the

batteries are low (the empty battery symbol ashes on the display and the parent unit beeps). The

parent unit starts indicating that the batteries are low 30 minutes before the batteries are

completely empty.

Note: If the batteries are completely empty, the parent unit automatically switches off and loses contact

with the baby unit.

1 Remove the lid of the compartment for the rechargeable batteries (Fig. 6).

2 Insert the rechargeable batteries (Fig. 7).

Note: Make sure the + and - poles of the batteries point in the right direction.

3 Reattach the lid (Fig. 8).

4 Insert the small appliance plug into the charger, put the adapter in a wall socket and place the

parent unit in the charger (Fig. 9).

, The charging light on the charger goes on.

, The display shows a charging battery symbol to indicate that the parent unit is charging.

5 Leave the parent unit in the charger until the batteries are fully charged.

, During charging, the charging light on the charger stays on.

, When the batteries are fully charged, the display of the parent unit shows a full battery

symbol T.

- When you charge the parent unit for the rst time or after a long period of disuse, switch it

off and let it charge continuously for at least 10 hours.

- Charging normally takes 8 hours, but it takes longer when the parent unit is switched on while

charging. To keep the charging time as short as possible, switch off the parent unit during

charging.

- When the batteries are fully charged, the parent unit can be used cordlessly for up to 24 hours.

Note: When the parent unit is charged for the rst time, the operating time is less than 24 hours. The

batteries only reach their full capacity after you have charged and discharged them four times.

Note: When the parent unit is not in the charger, the batteries gradually discharge, even when the parent

unit is switched off.

using the appliance

1 Place the parent unit and the baby unit in the same room to test the connection (Fig. 10).

Make sure the baby unit is at least 1 metre/3 feet away from the parent unit.

2 Press and hold the on/off button 3 on the baby unit until the green power-on light goes

on. (Fig. 11)

Note: The power-on light always lights up green, even when there is no connection with the parent unit.

, The nightlight lights up briey and then goes out again.

, The battery light T lights up briey and then goes out again. (Fig. 12)

ENGLISH 9
