Out of range alert

When the parent unit is out of range of the baby unit, the parent unit beeps from time to time. The

LINK light on the parent unit ashes red.

Note: The LINK light on the parent unit also ashes red when the baby unit is switched off.

Microphone sensitivity

You can set the microphone sensitivity of the baby unit to the desired level with the SENSITIVITY

button on the parent unit. You can only change the microphone sensitivity when a connection

between the baby unit and the parent unit has been established, i.e. when the LINK light on the

parent unit lights up green continuously.

1 Briey press the SENSITIVITY button on the parent unit (Fig. 25).

, The sound level lights light up for approx. 2 seconds to indicate the current sensitivity level.

2 Briey press the volume + and - buttons on the parent unit until the desired microphone

sensitivity level for the baby unit has been reached.

, one light on = minimum sensitivity level

, all lights on = maximum sensitivity level

Note: When the microphone sensitivity of the baby unit is set to a high level, it picks up more sounds and

therefore transmits more often. As a result, the units consume more power.

Reset function

This function allows you to reset the parent unit and the baby unit to the default settings. You can

use this function if problems occur that you cannot solve by following the suggestions in chapter

‘Frequently asked questions’. You have to reset each unit separately.

1 Press the on/off button to switch off the parent unit. Remove the small plug from the parent

unit and the adapter from the wall socket (Fig. 13).

2 Press and hold the volume down (-) button. Put the small appliance plug in the parent unit

and put the adapter in the wall socket (Fig. 26).

3 Wait for the parent unit to complete its automatic restart at its default settings before you

release the volume down (-) button.

4 Proceed in the same way to reset the baby unit.

Default settings

Parent unit

- Loudspeaker volume: 1

- Microphone sensitivity: 5

Baby unit

- Loudspeaker volume: medium

- Nightlight: off

accessories

Belt clip

If the batteries of the parent unit are sufciently charged, you can take the unit with you inside and

outside the house if you attach the unit to your belt with the belt clip. This allows you to monitor

your baby while you are moving around.

Connecting the belt clip

1 Snap the belt clip onto the parent unit (Fig. 27).
