Operation

Connecting the Control Device (Thermostat)

1. Uncou

ple the terminals (A) attached to the tips of the white

wires coming out of the right side of the burner cover.

uncoupled, to the connectors (B) of the control device.

To Control Device

Terminals (A)

Connectors (B)

Heat Shielding Mat

To avoid unexpected re or trouble, NEVER use the heater on

combustible flooring unless the heat shielding mat, which is

available as an option, is used.

Operation with Portable Generator

Before operating the heater from a portable generator, please conrm that the generator has been

properly connected to the ground earth. Operating the generator without proper grounding may result

in electrical shock. Please refer to the owner’s manual supplied by the manufacturer of the generator.

The heater operates within the voltage range between 207 Volts and 253 Volts. Before plugging the heater into the

generator, the output voltage of the generator should be veried.

If the voltage does not measure in this range, the heater should not be plugged into the generator.

Maintenance

2. Connect both the male and female terminals,which are

・If the heater is controlled by another device(such as a thermostat or a timer),the heater could turn

itself on at any time.

・When the heater is controlled by another device,extra care must be taken to ensure that the

heater is not accidentally turned on without someone nearby who can immediately attend to any

problems when the heater is ignited,operating,and cooling off.

・Do not repair or service the heater if you have not been trained in repair and service of natural and

propane gas heaters.maintenance should only be carried out by authorized persons.

・To avoid any injury and/or trouble,never inspect or service the heater while it is burning,in

operation,hot or plugged-in.

・Make sure to close all gas supply valves before service of heater unit.
