Caiman VAL6 GN5 [3/24] Important manual information
![Caiman VAL6 GN5 [3/24] Important manual information](/views2/1150161/page3/bg3.png)
Important Manual Information
To the owner
Thank you for choosing a Shizuoka Seiki infrared gas heater. This Owner’s Manual contains information needed for
proper operation, maintenance and care. A thorough understanding of these simple instructions will help you obtain
maximum satisfaction from your new Shizuoka Seiki. If you have any questions about the operation or maintenance
of your infrared gas heater, please consult with your Shizuoka Seiki dealer. If you have any questions or want to
know more detailed information about the heater, please contact your dealer. If any irregular or missing pages are
found in this Manual, please contact your dealer and we will replace them with new ones.
In this Owner’s Manual, particularly important information is distinguished in the following ways.
“DANGER” means that failure to follow the given precaution (s) may lead to death, serious injury
and/or major re.
“WARNING” means that failure to follow the given precaution (s) may likely result in death, serious
injury, re and/or possible explosion.
“CAUTION” means that failure to follow the given precaution (s) may result in serious injury and/or
property damage.
Depending on the circumstances, even the category of “CAUTION” can lead to grave damage to persons and/or
property. Cautions and recommendations listed in each category are equally important for safe operation. Be sure
to follow the precautions in all 3 categories.
POINT:
A POINT provides key information to simplify and clarify procedures.
The following signs, used throughout this Manual, are dened as follows:
Prohibited
(This indicates “actions that are strictly forbidden”.)
Mandatory
(This indicates “actions or instructions” that must be carried out.)
Caution
(This indicates “actions” that require careful attention)
AS we cannot predict every possible dangerous situation while operating this heater, the contents described in
this Manual cannot fully foresee the entire range of possible dangers. When operating the heater or carrying out
daily inspection, please pay careful attention to the contents of this Manual and the Labels on the heater itself. In
addition, be constantly alert for factors that might affect the safe operation of the heater. Do not hesitate to stop
operation and contact your dealer if you have any questions about any matters not discussed in this Manual.
