User manual

SETTINGS - PROGRAMMING MODE

Percentage on bottom: sets the percentage of time that the robot dedicates to cleaning the bottom of the pool. A value between

0% and 100% can be set. The higher the value set, the longer the time dedicated to cleaning the bottom.

100%: the robot only works on the bottom.

50%: the robot works half the time on the bottom and half the time on the wall.

0%: when the robot nds a wall, it will travel up it until reaching the water surface.

Re-entry method: sets the charging position on the wall, following the wall as if it was positioned inside the pool.

Left: indicates the charging position on the left side of the wall.

Right: indicates the charging position on the right side of the wall.

Centre: indicates the charging position in the centre of the wall.

Travelling speed on the bottom: sets the travelling speed of the robot on the bottom in metres/minute. The higher the speed

set, the more space the robot covers. Set low speeds in small pools in relation to the maximum capacity of the robot. Set high

speeds in large pools or pools that dirty easily.

Date: function for setting the date.

Time: function for setting the time.

SETTING - WORKING TIMES

Weekly: function for programming the working days of the robot during the week. On days with the ag “active,” the robot will

perform the operating cycles according to the set working times.

Work schedule 1: function for setting the rst time slot of the robot’s working day. Set the start and end time of the working cycle.

Setting the time at “00:00 – 00:00” means the robot will not work during work schedule 1.

Work schedule 2: function for setting the second time slot of the robot’s working day. Set the start and end time of the working

cycle.

Setting the time at “00:00 – 00:00” means the robot will not work during work schedule 2.

The setting of the time is essential for the robot’s proper functioning. Many parameters should be taken into consideration when

setting the work time such as the size, shape, ease with which it gets dirty, frequency of use, etc. of the pool.

As a rule, it is recommended to follow these rules:

•

program the robot activity while the cleaning system of the robot is running. Dirt removed by the turbines will then be ltered

by the central system, improving the robot’s capacity.

•

start with a wide-ranging program and then reduce it when you are satised with the level of cleanliness.

•

program and leave the robot running every day.

•

check the lter of the robot. At rst, very frequently, and then decrease the frequency in relation to the dirt found in the lter.

SETTINGS - LANGUAGE OPTIONS

Function for selecting the display language of the user and format menu that is used to set and display the date and time of the

robot.

SETTINGS - DIAGNOSTICS

Displays any critical events or errors that occurred in the main components during the operation of the robot.

If major errors occur, refer to the “Troubleshooting” chapter or contact the technical service centre.
