User manual

•

The Manufacturer shall not be held liable if unoriginal spare parts are used.

•

Never use and recharge the robot in explosive and/or ammable environments.

•

Only use the battery charger and power supply unit supplied to recharge the robot. Improper use can cause electric shocks,

overheating or leakage of corrosive liquid from the battery. In case of leakage, the battery must be washed with water/

neutraliser; in case of contact with eyes, consult a physician.

TECHNICAL INFORMATION

TECHNICAL SPECIFICATIONS

Description

Model

045BA0

Robot dimensions (W x H x D) mm 410 x 320 x 460

Weight Kg 21

Ambient operating temperature Max °C

ROBOT 5°(Min) +35°(Max)

BATTERY CHARGER -10°(Min) +40°(Max)

Water protection class IP

ROBOT - IP68

BATTERY CHARGER - IP64

Maximum pool depth cm 500

Water, operating parameters

pH: 7.0-7.8

Temperature: 5-35°C

NaCl Max: 5,000 ppm

Chlorine Max : 4 ppm

Power Supply unit

Vin 100 - 240Vac.

Input Frequency range 50-60.

Vout 36Vcc - 5,0A.

Battery Lithium Ion - 25,2V - 13.8Ah

Avg. working time hh:mm 2:00

Avg. recharging time hh:mm 3:00

Travelling speed on the bottom Mt/min. 10 - 20

Travelling speed on the wall Mt/min. 8

Filters 2 Litres, mesh pitch of 0.5mm

Remote control console included
